Designed as an alternative to the traditional coach screw mainly used for timber to timber applications. Wafer head for improved clamping and a low profile finish. Stainless steel must be used where there is corrosive environment and/or the base material has inherent corrosive characteristics e.g. Green Oak.
Timber Frame Screw WAFER A2 SS

Timber Frame Screw WAFER A2 SS - 8.0 x 150 (Tube 20)

SKU: 150INDEXWSST
£33.46 inc. VAT
£40.29 Sale £33.46 inc. VAT
Description

TIMCO Wafer Head A2 Stainless Steel Timber Screws - 8.0 x 150

Designed as an alternative to the traditional coach screw mainly used for timber to timber applications. Wafer head for improved clamping and a low profile finish. Stainless steel must be used where there is corrosive environment and/or the base material has inherent corrosive characteristics e.g. Green Oak.

Wafer head countersunk and TX40 recess

Stainless Steel offers superior corrosion resistance, perfect for highly corrosive environments

Helix shank for removing debris and to improve clamping

Single slash point to reduce torque and the risk of timber splitting at low edge distance

25 ° sharp point and single lead for a fast start and improved thread acceptance

Size mm 8.0 x 150
Driver Bit Size TX40
Shank Type Helix
Substrates Hardwood, Softwood, Corrosive Wood (e.g. Oak, Cedar)
Pack Quantity Unit Pieces
Pack Quantity 20
Point Type 25 ° Sharp with Single Slash
Recess Type TX Drive
Thread Type Serrated
Thread Dia. mm 8
Product Code 150INDEXWSST
Description Designed as an alternative to the traditional coach screw mainly used for timber to timber applications. Wafer head for improved clamping and a low profile finish. Stainless steel must be used where there is corrosive environment and/or the base material has inherent corrosive characteristics e.g. Green Oak.
Colour Silver
Material Austenitic Stainless Steel (A2-304)
Thread Length mm 70
Head Type Wafer
Pack Type Tube
SKU Barcode 5056110836300
Corrosion Rating 4 - Urban & industrial areas with a moderate salt atmosphere
Head Dia. mm 20.84
Included Items TX40 S2 Bit (Qty 1)
Length mm 150
CE Standard Web BS EN 14592:2008
Inner Thread Dia. mm 5.6
Fixed Washer Dia. mm 21
Carton Qty Packs 24
Carton Qty pcs 480
Pack Dimensions L x W x H mm 58 x 58 x 138
Pack Weight kg 0.8
Thread Coverage Partially Threaded
