Door rack bolts are an ideal way to increase security on timber doors. They are morticed into the door and operated by a spline key that throws the bolt into the frame. For optimum security it is recommended that he bolts or fitted to the top and the bottom of the window.
Door Rack Bolt Sat. Chrome

Door Rack Bolt Sat. Chrome - 60mm (Bag 2)

SKU: 200789
£7.17 inc. VAT
£8.63 Sale £7.17 inc. VAT
Description

TIMCO Door Rack Bolts Satin Chrome - 60mm

Door rack bolts are an ideal way to increase security on timber doors. They are morticed into the door and operated by a spline key that throws the bolt into the frame. For optimum security it is recommended that he bolts or fitted to the top and the bottom of the window.

Faceplate Size H x W mm 42 x 20
Pack Quantity 2
Bolt Throw mm 18
SKU Barcode 5056110822082
Material Steel
Case Dia. mm 16
No. of CSK Screws 6
Product Code 200789
Backset mm 31
Bolt Dia. mm 13
Corrosion Rating 2 - Occasionally damp/wet, rural and sheltered areas
Included Items Key (Qty 1)
Faceplate Type Square
Keep Size H x W mm 42 x 20
Finish Satin Chrome
Pack Type Bag
Pack Quantity Unit Pieces
Description Door rack bolts are an ideal way to increase security on timber doors. They are morticed into the door and operated by a spline key that throws the bolt into the frame. For optimum security it is recommended that he bolts or fitted to the top and the bottom of the window.
Screw Size imp. 4 x 5/8
Case Depth mm 60
Screw Size mm 3.0 x 15
Pack Dimensions L x W x H mm 150 x 70 x 70
Pack Weight kg 0.22
Carton Qty Packs 50
Carton Qty pcs 100
