Hex Screw W16 S/DRILL No5 EXT - 5.5 x 100 (Box 100)
Regular price
£29.09
inc. VAT
Regular price
£34.97
Sale
Sale price
£29.09
inc. VAT
TIMCO Self-Drilling Heavy Section Screws Exterior Silver with EPDM Washer - 5.5 x 100
Used for attaching metal to heavy section steel (Max. 12mm) without the need to pre-drill a hole. NOTE: Partially threaded.
Exterior plating gives a reliable and durable corrosion resistant coating which resists 1,000 hours salt-spray
| Pack Type | Box |
| Product Code | H100W16B |
| Pack Quantity | 100 |
| Description | Used for attaching metal to heavy section steel (Max. 12mm) without the need to pre-drill a hole. NOTE: Partially threaded. |
| Fixed Washer Dia. mm | 12 |
| Effective Thread Length mm | 53 *P/T |
| SKU Barcode | 5055331815071 |
| Pack Quantity Unit | Pieces |
| Finish | Exterior (Silver Organic) |
| Corrosion Rating | 3 - Urban & industrial areas with a low salt atmosphere |
| Rec RPM | 1,000 - 1,800 |
| Substrates | Steel |
| Material | Case & Core Hardened Carbon Steel |
| EPDM Washer mm | 16 |
| Length mm | 100 |
| Size mm | 5.5 x 100 |
| Point Type | Self-Drilling No.5 |
| Head Type | Hex |
| Type | For Heavy Section Steel |
| Thread Type | *P/T = Partially Threaded, Metric with V Flutes & Torque Relieving Slash |
| Thread Dia. mm | 5.5 |
| Included Items | 16mm EPDM Washers |
| Carton Qty pcs | 1200 |
| Carton Qty Packs | 12 |
| Socket Size mm | 8 |
| Drill Tip Length mm | 15 |
| Head Height mm | 5.6 |
| Approval | BS EN 10666 (DIN 7504) |
| Max Drilling Thickness mm | 12 |
| Pack Dimensions L x W x H mm | 190 x 90 x 90 |
| Pack Weight kg | 1.664 |
| Thread Coverage | Partially Threaded |
